Name: IP67 Waterproof Connector 3+5 Pin M19 Male Female Quick Release Plug Socket
Brand: Shenzhen Ulinkcon Technology Co., Ltd.
SKU: M19
Availability: InStock

Casa Prodotti Multi Pin Connectors Waterproof

IP67 Waterproof Connector 3+5 Pin M19 Male Female Quick Release Plug Socket

Dettagli:

Luogo di origine:	Cina
Marca:	Ulinkcon
Certificazione:	CE/Rohs/TUV/UL
Numero di modello:	M19

Termini di pagamento e spedizione:

Quantità di ordine minimo:	Negoziazione
Prezzo:	Negoziabile
Imballaggi particolari:	1. sacchetto di plastica;2. Cartone;3.Secondo le esigenze del cliente
Tempi di consegna:	3-6 giorni lavorativi
Termini di pagamento:	T/T,D/P,L/C,D/A,,Western Union,MoneyGram
Capacità di alimentazione:	100000 coppie Montly

Contatto

Descrizione di prodotto dettagliata

Valutazione attuale:	15A	Tensione nominale:	300 V
SPILLO:	3+5Pin	Tipo di connettore:	Connettore rapido
Materiale:	Nylon	Genere:	Da maschio a femmina
Evidenziare:	IP67 waterproof M19 connector , 3+5 pin quick release plug , M19 male female socket

IP67 Waterproof Connector 3+5 Pin M19 Male Female Quick Release Plug Socket

Product Overview

M19 3+5 Pin IP67 Circular Plug and Socket Connectors designed for reliable performance in demanding industrial environments.

Environmental Protection

IP67 waterproof and dustproof rated, providing complete protection against dust ingress and temporary immersion up to 1 meter for 30 minutes. Ideal for harsh outdoor conditions including rain, sand, dust, and heavy fog environments.

Power & Signal Separation

3+5 Pin shunt layout design with 3 pins dedicated to stable power transmission and 5 pins for multi-channel signal synchronization, preventing interference between power and signal lines.

Quick Release Design

Push-lock quick release system enables tool-free installation and maintenance with anti-misplug protection to prevent accidental disconnection.

Electrical Specifications

Parameter	Specification
Number of Poles	3+5 Pin
Current Rating	15A max
Voltage Rating	300VAC max
Dielectric Strength	1500VAC @ 60 s

Technical Specifications

Parameter	Specification
Contact Resistance	10 mΩ max
Insulation Resistance	500 MΩ at 500VDC
Operating Temperature	-40°C to +105°C
IP Rating	IP67 (1m / 30min) when mated
Mold Material	PA66
Contact/Terminal Material	Gold Plated Brass
Seal Material	Silicone

Operation Parameters

Parameter	Specification
Voltage Rating	300VAC max
Current Rating	5A max
Wire Size OD (Min)	3.0mm - 6.0mm
Wire Size OD (Max)	8.0mm - 10.0mm
Max Cable Cross Section	0.5mm² - 2.5mm²

Configuration Options

Push lock quick release system
Multiple core options: 2Pin, 3Pin, 4Pin, 5Pin for Power
Power-signal combinations: 3+2Pin, 3+3Pin, 3+4Pin, 3+5Pin, 3+9Pin and 2+20Pin
Signal options: 6Pin, 7Pin, 8Pin, 9Pin, 10Pin, 11Pin, 12Pin, 14Pin, 16Pin and 18Pin
Field assembly versions: wire to wire and wire to board options
Current rated 20A for continuous operation
Cable assembly service supported with custom options
OEM/ODM services available
